Korg SOUNDLINK MW-1608 NT Hybrid Analog/Digital Audio Mixer
Key Specs
| Max I/O Capacity | 16x Input / 20x Output |
|---|---|
| Number of Analog Input Channels | 16 (8 Mono / 4 Stereo) |
| Number of Mic Preamps | 12 |
| Number of Analog Output Channels | 20 |
| Faders & Level Adjustment | 18x 2.4" / 60 mm Non-Motorized Fader |
| Built-In Effects | 12x Stereo Reverb 4x Stereo Delay 1x Stereo Flanger 1x Stereo Chorus |
| Analog Inputs | 13x XLR TRS Balanced Mic Input 8x 1/4" TRS Balanced/Unbalanced Line Input 8x 1/4" TRS Balanced/Unbalanced Stereo Line Input (8 Stereo Pairs) |
| Analog Outputs | 2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair) 2x 1/4" TRS Balanced Stereo Main Output (1 Stereo Pair) 2x 1/4" TRS Stereo Monitor Output (1 Stereo Pair) 4x XLR 3-Pin Balanced Stereo Aux Send 2x 1/4" TRS Stereo Aux/Headphone Send 8x 1/4" TRS Balanced/Unbalanced Bus Output |
| Digital I/O | 0x DB25 |
| USB I/O | 1x USB-B 2.0 (2-Track Record, Audio Playback) |
| Wireless | No |
| Rack Mountable | No |
| Number of Analog Input Channels | 16 (8 Mono / 4 Stereo) |
|---|---|
| Number of Mic Preamps | 12 |
| Number of Analog Output Channels | 20 |
| Mix Routing | 8x Mono Bus 2x Mono Aux Send 2x Stereo Aux Send 1x Stereo Main LRC |
| Groups | 8x Subgroup 4x Mute Group |
| Presets | 20x Preset (Factory) |
| Display | Main Display: LCD |
| Faders & Level Adjustment | 18x 2.4" / 60 mm Non-Motorized Fader |
| Meters | Main Meter: 2x 12-Segment LED |
| Gain/Trim Range | XLR Mic Input: -10 dBu to +60 dBu 1/4" Line Input: +10 dBu to +60 dBu |
| Dynamic Processing | Input Channels: Compressor Master: Compressor, Limiter, Gate |
| EQ | Input Channels: 3-Band EQ (Mono Channels) 4-Band EQ (Stereo Channels) Outputs: 9-Band Graphic (Stereo Channels) |
| EQ Parameters | 1x HF Shelf: ±15 dB at 12 kHz (Mono Channels) 1x MF Notch/Peak: ±15 dB at 250 Hz to 5 kHz (Mono Channels) 1x LF Shelf: ±15 dB at 100 Hz (Mono Channels) 1x HF Shelf: ±15 dB at 12 kHz (Stereo Channels) 1x MF Notch/Peak: ±15 dB at 2.5 kHz (Stereo Channels) 1x MF Notch/Peak: ±15 dB at 250 Hz (Stereo Channels) 1x LF Notch/Peak: ±15 dB at 100 Hz (Stereo Channels) |
| Graphic EQ | Yes |
| Filters | Mono Channels: 1x High-Pass: 100 Hz, 18 dB/Octave |
| Solo/Mute | PFL per Input Channel |
| Built-In Effects | 12x Stereo Reverb 4x Stereo Delay 1x Stereo Flanger 1x Stereo Chorus |
| Audio Delay | No |
| Sample Rates | Up to 48 kHz |
| Bit Depth | 24-Bit |
Performance
| Frequency Response | 20 Hz to 20 kHz +0.5/-1.5 dBu |
|---|---|
| Headphone Output Power | 100 mW per Channel into 32 Ohms |
| I/O Impedance | Input: 3 Kilohms Output: 75 Ohms |
| SNR | Analog Input to Main Output: -70 dB |
| THD | Analog Input to Main Output: 0.004% (+4 dBu, 2901653245,2901837170) |
| Signal Generator | Sine, White, Pink Noise |
Connectivity
| Analog Inputs | 13x XLR TRS Balanced Mic Input 8x 1/4" TRS Balanced/Unbalanced Line Input 8x 1/4" TRS Balanced/Unbalanced Stereo Line Input (8 Stereo Pairs) |
|---|---|
| Analog Outputs | 2x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair) 2x 1/4" TRS Balanced Stereo Main Output (1 Stereo Pair) 2x 1/4" TRS Stereo Monitor Output (1 Stereo Pair) 4x XLR 3-Pin Balanced Stereo Aux Send 2x 1/4" TRS Stereo Aux/Headphone Send 8x 1/4" TRS Balanced/Unbalanced Bus Output |
| Phantom Power | +48 V |
| Digital I/O | 0x DB25 |
| MIDI I/O | No |
| USB I/O | 1x USB-B 2.0 (2-Track Record, Audio Playback) |
| Expansion Ports | No |
| Wireless | No |
| External Display I/O | No |
Recording
| Max Multitrack Recording | 2 Tracks |
|---|
Compatibility
| OS Compatibility | macOS / Windows |
|---|---|
| OS Compatibility | macOS Windows |
Power
| Input Power | 100 to 240 VAC, 50 / 60 Hz |
|---|
Physical
| Rack Mountable | No |
|---|---|
| Dimensions | 15.6 x 7.4 x 20.9" / 39.6 x 18.7 x 53 cm |
| Weight | 17.6 lb / 8 kg |
Packaging Info
| Package Weight | 21.32 lb |
|---|---|
| Box Dimensions (LxWxH) | 24.6 x 18.6 x 10.3" |
Identifiers
| MPN | MW-1608 |
|---|---|
| GTIN / EAN / UPC | 4959112191174 |
