Blackmagic Design Pocket Cinema Camera 6K G2
Imaging
| Lens Mount | Canon EF |
|---|---|
| Lens Communication | Yes, with Autofocus Support |
| Sensor Resolution | Effective: 21.2 Megapixel (6144 x 3456) |
| Sensor Type | 23.1 x 12.99 mm (Super35) CMOS |
| Image Stabilization | None |
| Built-In ND Filter | None |
| Internal Filter Holder | No |
| Capture Type | Stills & Video |
Exposure Control
| Shutter Type | Electronic Rolling Shutter |
|---|---|
| ISO Sensitivity | 100 to 25,600 |
| Shutter Angle | 5 to 360° |
| Advertised Dynamic Range | 13 Stops |
Internal Video Capture
| Raw Recording | Raw 6144 x 3456 at 23.98/24.00/25/29.97/50 fps (49 to 483 MB/s) 6144 x 2560 at 23.98/24.00/25/29.97/50/59.94/60 fps (37 to 359 MB/s) 5744 x 3024 up to 23.98/24.00/25/29.97/50/59.94/60 fps (40 to 395 MB/s) 4096 x 2160 at 23.98/24.00/25/29.97 fps (28 to 163 MB/s) 3728 x 3104 at 23.98/24.00/25/29.97 fps (36 to 265 MB/s) 2868 x 1512 at 23.98/24.00/25/29.97 fps (14 to 101 MB/s) |
|---|---|
| Recording Modes | ProRes 422/ProRes 422 HQ/ProRes 422 Proxy/ProRes 422LT DCI 4K (4096 x 2160) up to 59.94p UHD 4K (3840 x 2160) up to 59.94p Full HD (1920 x 1080) up to 119.88p |
| Sensor Crop While Recording | 6K (6144 x 2560) in 2.4:1 When Recording in Raw 5744 x 3024 When Recording in Raw 4K (4096 x 2160) When Recording in Raw 3728 x 3104 When Recording in Raw 2868 x 1512 When Recording in Raw |
| Variable Frame Rates | 6K: Up to 60 fps 1080p: Up to 119.88 fps |
| Recording Limit | Unlimited |
| Built-In Microphone Type | Stereo |
External Video Capture
| Raw Output | USB: 6144 x 3456 at 23.98/24.00/25/29.97/50 fps 6144 x 2560 at 23.98/24.00/25/29.97/50/59.94/60 fps 5744 x 3024 at 23.98/24.00/25/29.97/50/59.94/60 fps |
|---|---|
| External Recording Modes | 4:2:2 10-Bit via HDMI |
| IP Streaming | None |
Interface
| Media/Memory Card Slot | Slot 1: SD/SDHC/SDXC (UHS-II) Slot 2: CFast |
|---|---|
| Video I/O | 1 x HDMI Output |
| Audio I/O | 2 x Mini XLR Mic/Line (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x Weipu SF610/S2 (12 to 20 VDC) Input |
| Other I/O | 1 x USB Type-C (USB 3.2 / 3.1 Gen 1) Control/Video Output 1 x 1/8" / 3.5 mm (Timecode) Input (Shared with Mic/Line Input) |
| Wireless | Bluetooth Control |
| Global Positioning (GPS, GLONASS, etc.) | None |
Monitor
| Size | 5" |
|---|---|
| Resolution | 1920 x 1080 |
| Display Type | Tilting Touchscreen LCD |
| Type | Optional, Not Included |
Focus
| Focus Type | Auto and Manual Focus |
|---|
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
|---|---|
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Operating Humidity | 0 to 90% |
General
| Battery Type | Sony L-Series |
|---|---|
| Tripod Mounting Thread | 2 x 1/4"-20 Female |
| Accessory Mount | 1 x 1/4"-20 Female |
| Material of Construction | Carbon Fiber, Polycarbonate |
| Dimensions (W x H x D) | 7.08 x 4.84 x 4.41" / 17.98 x 12.29 x 11.2 cm |
| Weight | 2.65 lb / 1.20 kg |
Packaging Info
| Package Weight | 4.345 lb / 1.97 kg |
|---|---|
| Box Dimensions (LxWxH) | 10.1 x 6.9 x 6.9" |
Identifiers
| MPN | BM-CINECAMPOCHD2 |
|---|---|
| GTIN / EAN / UPC | 9338716007824 |
