Camcorder Sony FDR-AX43A UHD 4K Handycam
Camera
| Sensor Type | 1/2.5"-Type CMOS Sensor |
|---|---|
| Sensor Resolution | Actual: 8.57 Megapixel Effective: 8.29 Megapixel |
Optics
| Focal Length | 4.44 to 88mm |
|---|---|
| 35mm-Equivalent Focal Length | 26.8 to 536mm at 16:9 32.8 to 656mm at 4:3 |
| Maximum Aperture | f/2 to 3.8 |
| Minimum Focus Distance | 0.4" / 1.0 cm |
| Fixed Focus | No |
| Zoom | Optical: 20x Clear Image Zoom: 30x 4K Clear Image Zoom: 40x (in HD) Digital: 250x (in HD) |
| Filter Size | 55 mm |
Recording
| System | NTSC |
|---|---|
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC/Memory Stick Duo Hybrid |
| Video Format | 3840 x 2160p at 24/30 fps (100, 60 Mb/s XAVC S) 1920 x 1080p at 24/30/60 fps (50 Mb/s XAVC S) 1920 x 1080p at 60 fps (28 Mb/s AVCHD) 1920 x 1080p at 24 fps (24 Mb/s AVCHD) 1920 x 1080p at 24 fps (17 Mb/s AVCHD) 1920 x 1080i at 60 fps (24 Mb/s AVCHD) 1920 x 1080i at 60 fps (17 Mb/s AVCHD) 1440 x 1080i at 60 fps (9 Mb/s AVCHD) 1440 x 1080i at 60 fps (5 Mb/s AVCHD) 1280 x 720p at 30 fps (3 Mb/s MP4) |
| Still Image Support | JPEG 16.6 MP (5440 x 3056) JPEG 12.5 MP (4080 x 3056) JPEG 8.3 MP (3840 x 2160) JPEG 6.2 MP (2880 x 2160) JPEG 2.1 MP (1920 x 1080) JPEG .3 MP (640 x 480) |
| Channels | 5.1-Channel |
| Audio Format | AAC-LC Dolby Digital 2ch Dolby Digital 5.1 LPCM |
| Sampling Frequency | LPCM: 48.0 kHz |
| Bit Rate | LPCM: 16.0-Bit |
Display
| Display Type | Tilting Touchscreen LCD |
|---|---|
| Size | 3.0" |
Exposure Control
| Shutter Speed | 1/10000 to 8 Seconds in Photo Mode |
|---|---|
| Shooting Modes | Auto M (Manual) |
| Interval Recording | 1 Second 2 Second 5 Second 10 Second 30 Second 60 Second |
| Self-Timer | 10 Sec |
Features
| Image Stabilization | Optical |
|---|---|
| Scene Modes | Preset: Yes |
| White Balance Modes | Auto Indoor 1 Onepush Outdoors |
| Creative Effects | Yes |
| Built-In Mic | Yes |
| Built-In Speaker | Yes |
| Built-In Light/Flash | Light - No Flash - No |
| Accessory Shoe | 1 x Multi Interface Shoe |
| Tripod Mounting Thread | 1/4"-20 Female |
Input/Output Connectors
| Video I/O | 1 x Micro-HDMI Output |
|---|---|
| Other I/O | 1 x Sony Multi/USB Micro-B Control/Video |
| Wireless | 2.4 GHz Wi-Fi (802.11b/g) |
General
| Supported Languages | Brazilian Portuguese English French Spanish |
|---|---|
| Battery | Rechargeable Lithium-Ion Battery Pack, 6.8 VDC, 1960 mAh |
| Charging Method | AC Adapter |
| Power Adapter | 100 - 240 VAC, 50 / 60Hz |
| Power Consumption | In LCD Operation: 4.9 W In Viewfinder Operation: 4.9 W |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Dimensions (W x H x D) | 6.8 x 3.2 x 2.9" / 173 x 80.5 x 73 mm |
| Weight | 22.05 oz / 625 g (With Battery) |
Packaging Info
| Package Weight | 2.4 lb / 1.09 kg |
|---|---|
| Box Dimensions (LxWxH) | 7.6 x 6.6 x 4.2" |
Identifiers
| MPN | FDRAX43AB.CEE |
|---|---|
| GTIN / EAN / UPC | 4548736141254 |
