Digital Mirrorless Camera Panasonic Lumix DC-S5 with 20-60mm Lens
| Lens Mount | Leica L |
|---|---|
| Sensor Type | 35.6 x 23.8 mm (Full-Frame) CMOS |
| Sensor Resolution | Actual: 25.28 Megapixel Effective: 24.2 Megapixel (6000 x 4000) |
| Crop Factor | None |
| Aspect Ratio | 1:1, 2:1, 3:2, 4:3, 16:9, 65:24 |
| Image File Format | JPEG, Raw |
| Bit Depth | 14-Bit |
| Image Stabilization | Sensor-Shift, 5-Axis |
| ISO Sensitivity | Auto, 100 to 51200 (Extended: 50 to 204800) |
|---|---|
| Shutter Speed | Mechanical Shutter 1/8000 to 60 Second 0 to 30 Minute in Bulb Mode Electronic Front Curtain Shutter 1/2000 to 60 Second 0 to 30 Minute Electronic Shutter 1/8000 to 60 Second 0 to 60 Second in Bulb Mode 1/16000 to 1/25 Second in Movie Mode |
| Metering Method | Center-Weighted Average, Highlight Weighted, Multi-Zone, Multiple, Spot |
| Exposure Modes | Aperture Priority, Manual, Program, Shutter Priority |
| Exposure Compensation | -5 to +5 EV (1/3 EV Steps) |
| Metering Range | 0 to 18 EV |
| White Balance | Auto, Cloudy, Color Temperature, Daylight, Flash, Incandescent, Shade, White Set |
| Continuous Shooting | Mechanical Shutter Up to 7 fps at 24.2 MP for up to 24 Frames (Raw) / 999 Frames (JPEG) Electronic Shutter Up to 7 fps at 24.2 MP for up to 24 Frames (Raw) / 999 Frames (JPEG) Up to 30 fps at 18 MP Up to 60 fps at 8 MP Up to 30 fps at 8 MP |
| Interval Recording | Yes |
| Self-Timer | 2/10-Second Delay |
| Recording Modes | H.264/MOV 4:2:2 10-Bit UHD 4K (3840 x 2160) at 23.976p/25p/29.97p (150 Mb/s) Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p (100 Mb/s) 4K Anamorphic (3328 x 2496) at 23.976p/25p/29.97p (150 Mb/s) H.264/MOV 4:2:0 8-Bit UHD 4K (3840 x 2160) at 23.976p/25p/29.97p/50p/59.94p (100 to 150 Mb/s) Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p (100 Mb/s) 4K Anamorphic (3328 x 2496) at 23.976p/25p/29.97p/50p (100 to 150 Mb/s) H.265/MOV 4:2:0 10-Bit UHD 4K (3840 x 2160) at 50p/59.94p (200 Mb/s) 4K Anamorphic (3328 x 2496) at 50p (200 Mb/s) H.265/MP4 4:2:0 10-Bit UHD 4K (3840 x 2160) at 23.976p/25p/29.97p/50p/59.94p (72 to 100 Mb/s) H.264/MP4 4:2:0 8-Bit UHD 4K (3840 x 2160) at 23.976p/25p/29.97p (100 Mb/s) Full HD (1920 x 1080) at 23.976p/25p/29.97p/50p/59.94p/100p/119.88p/180p (20 to 28 Mb/s) |
|---|---|
| External Recording Modes | 4:2:2 10-Bit UHD 4K (3840 x 2160) up to 50p/59.94p |
| Recording Limit | Up to 30 Minutes for UHD 4K (3840 x 2160) at 23.976p/25p/29.97p(4:2:2 10-Bit) Up to 30 Minutes for UHD 4K (3840 x 2160) at 50p/59.94p(4:2:0 10-Bit) Unlimited for UHD 4K (3840 x 2160) at 23.976p/25p/29.97p(4:2:0 8-Bit) |
| Video Encoding | NTSC/PAL |
| Audio Recording | Built-In Microphone (Stereo) External Microphone Input |
| Audio File Format | AAC, Linear PCM |
| Focus Type | Auto and Manual Focus |
|---|---|
| Focus Mode | Continuous-Servo AF (C), Manual Focus (M), Single-Servo AF (S) |
| Autofocus Points | Contrast Detection: 225 |
| Autofocus Sensitivity | -6 to +20 EV |
| Viewfinder Type | Electronic (OLED) |
|---|---|
| Viewfinder Resolution | 2,360,000 Dot |
| Viewfinder Eye Point | 20 mm |
| Viewfinder Coverage | 100% |
| Viewfinder Magnification | Approx. 0.74x |
| Diopter Adjustment | -4 to +4 |
| Size | 3.0" |
|---|---|
| Resolution | 1,840,000 Dot |
| Display Type | Articulating Touchscreen LCD |
| Built-In Flash | No |
|---|---|
| Flash Modes | Auto, Auto/Red-Eye Reduction, Forced On, Forced On/Red-Eye Reduction, Off, Slow Sync, Slow Sync/Red-Eye Reduction |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3 EV Steps) |
| Dedicated Flash System | TTL |
| External Flash Connection | Hot Shoe |
| Media/Memory Card Slot | Slot 1: SD/SDHC/SDXC (UHS-II) Slot 2: SD/SDHC/SDXC (UHS-I) |
|---|---|
| Connectivity | USB Type-C (USB 3.1), HDMI D (Micro), 3.5mm Microphone, 3.5mm Headphone, 2.5mm Sub-Mini |
| Wireless | Bluetooth Wi-Fi |
| GPS | No |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
|---|---|
| Operating Humidity | 10 to 80% |
| Battery | 1 x DMW-BLK22 Rechargeable Lithium-Ion, 2200 VDC, 7.2 mAh (Approx. 440 Shots) |
|---|---|
| Dimensions (W x H x D) | 5.22 x 3.82 x 3.22" / 132.6 x 97.1 x 81.9 mm |
| Weight | 1.57 lb / 714 g (Body with Battery and Memory) 1.39 lb / 630 g (Body Only) |
| Focal Length | 20 to 60mm |
|---|---|
| Maximum Aperture | f/3.5 to 5.6 |
| Minimum Aperture | f/22 |
| Angle of View | 94° to 40° |
| Maximum Magnification | 0.43x |
| Minimum Focus Distance | 5.91" / 15 cm |
| Optical Design | 11 Elements in 9 Groups |
| Diaphragm Blades | 9, Rounded |
| Focus Type | Autofocus |
| Image Stabilization | No |
| Filter Size | 67 mm (Front) |
| Dimensions (ø x L) | 3.05 x 3.43" / 77.4 x 87.2 mm |
| Weight | 12.35 oz / 350 g |
| Package Weight | 4.25 lb / 1.93 kg |
|---|---|
| Box Dimensions (LxWxH) | 11.25 x 6 x 5.5" |
