LG S80TR 580W 5.1.3-Channel Soundbar System Black
Key Specs
| Channel Configuration | 5.1.3-Channel |
|---|---|
| Low-Frequency Drivers | 0x |
| High-Frequency Drivers | 0x |
| Full-Range Drivers | 3x Front-Firing 3x Up-Firing |
| Amplifier Output | 260 W RMS |
| Satellite Speaker Configuration | Full-Range |
| Subwoofer Driver | 1 |
| Subwoofer Amplifier Output | 220 W RMS |
| Subwoofer Inputs/Outputs | Wireless |
| Inputs | 1x HDMI - Audio/Video 1x Optical TOSLINK - Audio |
| Outputs | 1x HDMI - eARC |
| Wireless | Wi-Fi 4 (802.11n) / Bluetooth 5.1 |
| Audio Decoding | DTS Digital Surround, DTS-HD, DTS-HD High-Resolution, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, PCM |
| HDMI Compliance | ARC, CEC, eARC |
| Wall Mountable | Yes, with Optional Hardware |
Soundbar
| Channel Configuration | 5.1.3-Channel |
|---|---|
| Low-Frequency Drivers | 0x |
| High-Frequency Drivers | 0x |
| Full-Range Drivers | 3x Front-Firing 3x Up-Firing |
| Amplifier Output | 260 W RMS |
| Impedance | 4 Ohms (Soundbar) |
| Total Harmonic Distortion (THD) | 10% |
Satellite Speakers
| Speaker Positioning | Rear |
|---|---|
| Satellite Speaker Configuration | Full-Range |
| Full-Range Drivers | 2x Front-Firing |
| Power Rating | 50 W RMS per Speaker |
| Satellite Inputs/Outputs | Wireless |
| Total Harmonic Distortion (THD) | 10% |
| Placement & Mounting Options | Rear: Tabletop/Bookshelf Wall-Mount (with Optional Hardware) |
Subwoofer
| Enclosure Type | Bass-Reflex |
|---|---|
| Subwoofer Driver | 1 |
| Subwoofer Amplifier Output | 220 W RMS |
| Impedance | 3 Ohms |
| Total Harmonic Distortion (THD) | 10% |
| Subwoofer Inputs/Outputs | Wireless |
Connectivity
| Inputs | 1x HDMI - Audio/Video 1x Optical TOSLINK - Audio |
|---|---|
| Outputs | 1x HDMI - eARC |
| USB I/O | 1x USB-A (Unspecified Interface) (Audio, Power) |
| Ethernet I/O | No |
| Wireless Audio Protocols | AirPlay 2, Bluetooth, Chromecast built-in, Proprietary |
| Wireless | Wi-Fi 4 (802.11n) / Bluetooth 5.1 |
| Bluetooth | 5.1 |
| NFC | No |
| Bluetooth Codec Support | AAC SBC |
| Mobile App Compatible | Yes: Android & iOS |
Compatibility
| Audio Decoding | DTS Digital Surround, DTS-HD, DTS-HD High-Resolution, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, PCM |
|---|---|
| Sampling Frequencies | Up to 192 kHz |
| HDMI Compliance | ARC, CEC, eARC |
| HDR Support | Yes, HDR10/Dolby Vision |
| HDCP Support | Yes, Version 2.3 |
| Supported File Formats | AAC, FLAC, MP3, OGG, WAV |
| Supported File Systems | FAT16, FAT32, NTFS |
Physical
| Environmental Resistance | No |
|---|---|
| Operating Conditions | 41 to 104°F / 5 to 40°C at 5 to 80% Humidity |
| Wall Mountable | Yes, with Optional Hardware |
| Recommended Screen Size | 55" and Up |
| Dimensions | 39.3 x 2.5 x 5.3" / 99.8 x 6.3 x 13.5 cm (Soundbar) 7.9 x 16 x 15.9" / 20.1 x 40.6 x 40.4 cm (Subwoofer) 3.9 x 6.9 x 4.7" / 9.9 x 17.5 x 11.9 cm (Satellites) |
| Weight | 9.9 lb / 4.5 kg (Soundbar) 22.1 lb / 10 kg (Subwoofer) 5.1 lb / 2.3 kg (Each Satellite) |
Packaging Info
| Package Weight | 50.05 lb |
|---|---|
| Box Dimensions (LxWxH) | 43 x 22.91 x 10.25" |
Identifiers
| MPN | S80TR.DEUSLLK |
|---|---|
| GTIN / EAN / UPC | 8806096055014 |
