LG SG10TY 420W 3.1-Channel Soundbar System
Key Specs
| Channel Configuration | 3.1-Channel |
|---|---|
| Full-Range Drivers | 5x |
| Subwoofer Driver | 1 |
| Subwoofer Amplifier Output | 220 W RMS |
| Subwoofer Inputs/Outputs | Wireless |
| Inputs | 1x HDMI - eARC 1x HDMI 1x Optical TOSLINK |
| Outputs | No |
| Wireless Audio Protocols | AirPlay 2, Bluetooth, Chromecast built-in, Spotify Connect, TIDAL Connect, Wi-Fi |
| Wireless | Wi-Fi 4 (802.11n) / Bluetooth 5.1 |
| Audio Decoding | DTS Digital Surround, DTS-HD, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby TrueHD, LPCM, PCM |
| HDMI Compliance | ARC, CEC, eARC |
| Wall Mountable | Yes, with Included Hardware |
Soundbar
| Channel Configuration | 3.1-Channel |
|---|---|
| Full-Range Drivers | 5x |
| Amplifier Output | 200 W RMS |
| Impedance | 4 Ohms |
| Total Harmonic Distortion (THD) | 10% |
Subwoofer
| Enclosure Type | Bass-Reflex |
|---|---|
| Subwoofer Driver | 1 |
| Subwoofer Amplifier Output | 220 W RMS |
| Impedance | 3 Ohms |
| Total Harmonic Distortion (THD) | 10% |
| Subwoofer Inputs/Outputs | Wireless |
Connectivity
| Inputs | 1x HDMI - eARC 1x HDMI 1x Optical TOSLINK |
|---|---|
| Outputs | No |
| USB I/O | 1x USB-A (Unspecified Interface) (Audio) |
| Ethernet I/O | No |
| Wireless Audio Protocols | AirPlay 2, Bluetooth, Chromecast built-in, Spotify Connect, TIDAL Connect, Wi-Fi |
| Wireless | Wi-Fi 4 (802.11n) / Bluetooth 5.1 |
| Bluetooth | 5.1 |
| NFC | No |
| Bluetooth Codec Support | AAC SBC |
| Mobile App Compatible | Yes: Android & iOS |
Compatibility
| Audio Decoding | DTS Digital Surround, DTS-HD, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby TrueHD, LPCM, PCM |
|---|---|
| Sampling Frequencies | Up to 192 kHz |
| HDMI Compliance | ARC, CEC, eARC |
| HDR Support | Yes, HDR10/Dolby Vision/Hybrid Log Gamma |
| HDCP Support | Yes, Version 2.3 |
| Supported File Formats | AAC, FLAC, MP3, OGG, WAV |
| Supported File Systems | FAT16, FAT32, NTFS |
Power
| Power Consumption | 45 W (Soundbar) 33 W (Subwoofer) < 0.5 W (Standby) |
|---|---|
| Input Power | 100 to 240 VAC, 50 / 60 Hz |
Physical
| Environmental Resistance | No |
|---|---|
| Operating Conditions | 41 to 104°F / 5 to 40°C at 5 to 80% Humidity |
| Wall Mountable | Yes, with Included Hardware |
| Recommended Screen Size | 65" and Up |
| Dimensions | 56.9 x 5.9 x 1.3" / 1445.3 x 149.9 x 33 mm (Soundbar) 7.1 x 15.5 x 11.4" / 180.3 x 393.7 x 289.6 mm (Subwoofer) |
| Weight | 8.6 lb / 3.9 kg (Soundbar) 12.8 lb / 5.8 kg (Subwoofer) |
Packaging Info
| Package Weight | 35.5 lb |
|---|---|
| Box Dimensions (LxWxH) | 59.75 x 16.75 x 9.75" |
Identifiers
| MPN | SG10TY |
|---|---|
| GTIN / EAN / UPC | 8806091960146 |
