Yamaha MG12XU 12-Channel Mixing Console

Name: Yamaha MG12XU 12-Channel Mixing Console
Brand: Yamaha
SKU: MG12XU
Price: 416.45 EUR
Availability: BackOrder

✔ 6x Mic Inputs
✔ 12x Line Inputs
✔ 2-In/2-Out USB Up to 24-Bit / 192kHz
✔ Built-In FX with 24 Presets
✔ XLR and TRS 1/4″ Stereo Outs
✔ Two Group Buses & Two Aux Sends
✔ D-PRE Mic Preamps with 48V Phantom
✔ HPF and 3-Band EQ on Channels 1-8
✔ 1/4″ Headphone Output with Level Control
✔ USB Works with Windows, Mac and iOS

416,45€

Hinta sisältää 21% ALV:n

Tilattavissa (toimitus 2 - 7 arkipäivässä)

Maksa Klarnalla

Maksa heti, 30 päivän kuluttua tai osamaksulla.

2 vuoden takuu

Takuuhuollolla ilmainen palautus

14 päivän palautusoikeus

Turvallinen maksutapa

Kuvaus

Yamaha MG12XU 12-Channel Mixing Console

Built-in Effects	SPX algorithm: 24 programs, PARAMETER control:1, FOOT SW:1 (FX RTN CH on/off)
Phantom Power	+48 V switchable, channels 1 - 4
Digital I/O	USB: USB Audio Class 2.0 compliant Sampling frequency: max 192 kHz Bit depth: 24-bit
Input Channels	4x mono [mic/line] 2x mono/stereo [mic/line] 2x stereo [line]
Output Channels	2x stereo out 1x monitor out 1x headphone out 2x aux out 2x group out
Bus	Stereo: 1 AUX: 2 GROUP: 2
Pad	26 dB (mono)
HPF	80 Hz, 12 dB/oct (mono/stereo: MIC only)
Compressor	Threshold: +22 dBu to -8 dBu Ratio: 1:1 to 4:1 Output level: 0 dB to 7 dB Attack time: approx. 25 msec Release time: approx. 300 msec
Equalizer	EQ high gain: +15 dB/-15 dB, Frequency: 10 kHz shelving EQ mid gain: +15 dB/-15 dB, Frequency: 2.5 kHz peaking EQ low gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
LED	Peak LED turns on when post EQ signal reaches 3 dB below clipping
Level Metering	2 x 12-segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB]
Total Harmonic Distortion	0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min, 0.005% @ +24 dBu (1 kHz), GAIN knob: Min
Frequency Response	+0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1 kHz, GAIN knob: Min
Equivalent Input Noise	-128 dBu (mono input channel, Rs: 150 Ω, GAIN knob: max)
Residual Output Noise	-102 dBu (STEREO OUT, STEREO master fader: min)
Crosstalk	-78 dB
Power Requirement	AC 100 - 240 V, 50 / 60 Hz
Power Consumption	22 W
Dimensions	12.1 x 4.6 x 16.6" (308 x 118 x 422 mm)
Net Weight	9.3 lb (4.2 kg)

Packaging Info

Package Weight	13.05 lb
Box Dimensions (LxWxH)	19.1 x 15.6 x 8"

Identifiers

MPN	MG12XU
GTIN / EAN / UPC	4957812553865
