AMD Ryzen 5 8500G Processor Tray
General
| Product Name | AMD Ryzen™ 5 8500G |
|---|---|
| Family | AMD Ryzen |
| Series | AMD Ryzen 8000 Series |
| Form Factor | Desktop |
| Former Codename | Phoenix |
| Architecture | 2x Zen 4 + 4x Zen 4c |
| Launch Date | Q1 2024 |
| Regional Availability | Global |
Processor
| CPU Cores | 6 |
|---|---|
| CPU Threads | 12 |
| Multithreading | AMD SMT (Simultaneous Multithreading) |
| Base Clock | 3.5 GHz |
| Zen 4 Base Clock | 4.1 GHz |
| Zen 4c Base Clock | 3.3 GHz |
| Max Boost Clock | Up to 5.0 GHz |
| Max Zen 4c Clock | Up to 3.7 GHz |
| L2 Cache | 6 MB |
| L3 Cache | 16 MB |
| Total Cache | 22 MB |
| Instruction Set | x86-64 |
| CPU Boost Technology | AMD Precision Boost 2 |
Core Technology
| CPU Core Process | TSMC 4nm FinFET |
|---|---|
| CPU Compute Die Size | 137 mm² |
| Package Die Count | 1 |
| Core Configuration | 2 Zen 4 cores + 4 Zen 4c cores |
| Simultaneous Multithreading | Yes |
Socket
| CPU Socket | AM5 |
|---|---|
| Socket Type | LGA AM5 |
| Supported Chipsets | A620, X670E, X670, B650E, B650, X870E, X870, B840, B850 |
Memory
| Memory Type | DDR5 |
|---|---|
| Memory Subtype | UDIMM |
| Memory Channels | 2 |
| Maximum Memory | 96 GB DDR5 |
| Maximum LPDDR5 Memory | 64 GB |
| Maximum Memory Speed | DDR5-5200 with 2x1R or 2x2R configurations; DDR5-3600 with 4x1R or 4x2R configurations |
| ECC Support | Yes, requires platform support |
| AMD EXPO | Supported |
Graphics
| Graphics Model | AMD Radeon™ 740M Graphics |
|---|---|
| Graphics Architecture | AMD Radeon 700M Series |
| Graphics Core Count | 4 |
| Graphics Frequency | 2800 MHz |
| DirectX | DirectX 12 |
| FreeSync | AMD FreeSync supported |
| SmartAccess Memory | Supported |
| Multi-Monitor Support | Yes |
| Maximum Displays | Up to 4 |
| Wireless Display | Miracast |
Display Output
| DisplayPort Version | DisplayPort 2.1 |
|---|---|
| DisplayPort Features | Adaptive-Sync, HDR Metadata, UHBR10 |
| DisplayPort Maximum Resolution | 7680 x 4320 @ 60Hz |
| DisplayPort Maximum 4K Refresh | 3840 x 2160 @ 240Hz |
| HDMI Version | HDMI 2.1 |
| HDCP | HDCP 2.3 |
| USB Type-C DisplayPort | DisplayPort Alternate Mode supported |
PCI Express
| PCI Express Version | PCIe 4.0 |
|---|---|
| Native PCIe Lanes | 14 total / 10 usable |
| NVMe Support | Boot, RAID 0, RAID 1 |
Connectivity
| Native USB 4 | 2 ports, up to 40 Gbps |
|---|---|
| Native USB 3.2 Gen 2 | 2 ports, up to 10 Gbps |
| Native USB 2.0 | 1 port, up to 480 Mbps |
| USB 4 Speed | Up to 40 Gbps |
| USB 3.2 Gen 2 Speed | Up to 10 Gbps |
Power
| Default TDP | 65W |
|---|---|
| Configurable TDP | 45-65W |
| Maximum Operating Temperature | 95°C |
Overclocking and Performance
| AMD EXPO Memory Overclocking | Yes |
|---|---|
| Precision Boost Overdrive | Yes |
| Curve Optimizer | Voltage offsets supported |
| AMD Ryzen Master | Supported |
| Overclocking | Supports processor and memory tuning features through compatible platforms |
Instruction Extensions
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
|---|---|
| Virtualization | AMD-V |
| Security Instruction Support | AES, SHA |
Video Encoding
| H.264 Encoding | Supported |
|---|---|
| H.265 Encoding | Supported |
| AV1 Encoding | Supported |
| Maximum AV1 Encode | 4320p @ 60Hz |
Video Decoding
| MPEG-2 | Supported up to 1080p60 |
|---|---|
| VC-1 | Supported up to 1080p60 |
| VP9 | Supported up to 4320p |
| H.264 | Supported up to 4320p |
| H.265 | Supported up to 4320p |
| AV1 | Supported up to 4320p60 |
Security
| AMD Enhanced Virus Protection | Yes |
|---|---|
| Security Processor | AMD Secure Processor |
| NX Bit | Supported |
Operating System Support
| Windows | Windows 11 64-bit, Windows 10 64-bit |
|---|---|
| Linux | RHEL x86 64-bit, Ubuntu x86 64-bit |
Product IDs
| Tray Product ID | 100-000001491 / 100-000000931 |
|---|---|
| Boxed Product ID | 100-100000931BOX |
| MPK Product ID | 100-100000931MPK |
Processor Features
| AMD Ryzen Master Support | Yes |
|---|---|
| Precision Boost Overdrive | Yes |
| AMD EXPO Technology | Yes |
| AMD SmartAccess Memory | Available |
| Package | Desktop processor, tray version |
Identifiers
| MPN | 100-000000931 |
|---|---|
| GTIN / EAN / UPC | 5054444573694 |
