Huawei E5785-320a Router White
Network
| Technology | 4G LTE / 3G |
|---|---|
| 4G Category | LTE Cat 7 |
| 4G Bands | LTE FDD: B1 / B3 / B5 / B7 / B8 / B18 / B19 / B20 / B28 / B32 LTE TDD: B38 / B40 / B41 / B42 |
| 3G Bands | UMTS B1 / B5 / B8 |
| 4G Download Speed | Up to 300 Mbps |
| 4G Upload Speed | Up to 100 Mbps |
| LTE Carrier Aggregation | LTE FDD 2CC carrier aggregation supported |
| MIMO | 4G DL 2x2 MIMO; UL 1x1 MIMO |
Body
| Dimensions | 108 x 62 x 17.1 mm (4.25 x 2.44 x 0.67 in) |
|---|---|
| Weight | Approximately 127 g (including battery) |
| Colour | White |
| Form Factor | Portable 4G mobile Wi-Fi router |
Display
| Type | LCD |
|---|---|
| Size | 1.45 inches |
| Information | Displays device status and network information |
Wi-Fi
| Standard | IEEE 802.11a / b / g / n / ac |
|---|---|
| Frequency | 2.4 GHz / 5 GHz dual-band |
| 2.4 GHz Speed | Up to 300 Mbps theoretical |
| 5 GHz Speed | Up to 867 Mbps theoretical |
| Wi-Fi MIMO | 2x2 MIMO |
| Maximum Connections | Up to 32 devices simultaneously |
| Wi-Fi Antenna | Built-in dual-band Wi-Fi antenna, non-removable |
Memory
| RAM | 256 MB DDR |
|---|---|
| Storage | 256 MB NAND Flash |
SIM
| SIM Type | Micro-SIM (3FF) |
|---|---|
| SIM Slot | 1 x Micro-SIM card slot |
Interfaces
| USB | 1 x Micro USB 2.0 |
|---|---|
| USB Function | Charging and data connection |
| Ethernet | Not available |
Antenna
| 4G / 3G Antenna | Built-in LTE/UMTS main and diversity antennas |
|---|---|
| Wi-Fi Antenna | Built-in dual-band Wi-Fi antenna |
| Antenna Type | Internal antennas |
Battery
| Type | Rechargeable lithium-ion battery, removable |
|---|---|
| Capacity | 3000 mAh |
| Voltage | 3.8 V |
| Working Time | Up to 12 hours, depending on network conditions |
| Standby Time | Up to 700 hours, depending on network conditions |
Power
| Power Consumption | < 4.5 W |
|---|---|
| Input | 5 V / 2 A |
| AC Adapter | 100-240 V AC input |
| Charging Interface | Micro USB |
Security
| Security Modes | Open, WPA2-PSK, WPA/WPA2-PSK |
|---|---|
| Wi-Fi Security | Wireless encryption and password protection |
Controls
| Power Button | Yes |
|---|---|
| Menu Button | Yes |
| Reset Button | Yes |
Software
| Management App | HUAWEI AI Life App |
|---|---|
| Features | Traffic statistics, online software upgrade, Wi-Fi management and device configuration |
| WPS | Supported |
Features
| Portable Wi-Fi | Yes |
|---|---|
| Plug and Play | Yes |
| SMS | Supported |
| Traffic Statistics | Supported |
| Online Software Upgrade | Supported |
Environmental
| Operating Temperature | 0°C to 35°C |
|---|---|
| Storage Temperature | -20°C to +60°C |
| Operating Humidity | 5% to 95% relative humidity, non-condensing |
Connectivity
| Wi-Fi Coverage | Dual-band 2.4 GHz and 5 GHz wireless connectivity |
|---|---|
| Maximum Wi-Fi Users | Up to 32 simultaneous devices |
| Connection Type | 4G LTE mobile broadband to Wi-Fi |
Package
| Router | 1 x HUAWEI E5785-320a Mobile WiFi |
|---|---|
| Battery | 1 x rechargeable removable battery |
| USB Cable | 1 x 17 cm USB cable |
| Charger | 5 V / 2 A charger, market dependent or optional |
| Documentation | Quick Start Guide including safety information |
Identifiers
| MPN | E5785-320a |
|---|---|
| GTIN / EAN / UPC | 6941487253135, 6941487256839 |
