Pioneer VSX-LX305 silver home cinema receiver
Key Specs
| Product Type | 9.2-Channel Network AV Receiver |
|---|---|
| Channels | 9.2 |
| Amplifier Channels | 9 |
| Amplification Type | Direct Energy |
| Power Output | 100 W per Channel (8 Ohms, 20 Hz-20 kHz, THD 0.08%) |
| Maximum Power Output | 225 W per Channel (6 Ohms, 1 kHz, THD 10%) |
| Room Calibration | Dirac Live and Advanced MCACC |
Audio
| Dolby Formats | Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Surround |
|---|---|
| DTS Formats | DTS:X, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express |
| IMAX Enhanced | Yes |
| Dolby Atmos Height Virtualizer | Yes |
| Reflex Optimizer | Yes |
| Speaker Impedance | 4 to 16 Ohms |
Video
| HDMI Inputs | 6 Rear + 1 Front |
|---|---|
| HDMI Outputs | 2 |
| HDMI Version | HDMI 2.1 |
| Maximum Resolution | 8K Ultra HD |
| 8K Support | Up to 8K/60p |
| 4K Support | Up to 4K/120p |
| HDR Support | HDR10+, HDR10, Dolby Vision, HLG |
| VRR | Yes |
| ALLM | Yes |
| QMS | Yes |
| 8K Upscaling | Yes |
Connectivity
| Wi-Fi | Dual-Band 2.4/5 GHz |
|---|---|
| Bluetooth | Bluetooth 4.2 |
| Bluetooth Codec | SBC, AAC, aptX, aptX HD |
| AirPlay 2 | Yes |
| Chromecast Built-In | Yes |
| Ethernet | 1x RJ-45 |
| USB | 2x USB |
| HDMI eARC | Yes |
| Phono Input | 1x MM Phono |
| Optical Input | 1x |
| Coaxial Input | 1x |
| Headphone Output | 1x 6.3 mm |
Network & Streaming
| Streaming Services | Spotify, TIDAL, Deezer, Amazon Music |
|---|---|
| Network Audio | DTS Play-Fi, Chromecast, AirPlay 2, DLNA |
| Internet Radio | TuneIn |
| Multi-Room | Zone 2 and Zone B |
| Sonos Compatible | Yes |
| Roon Tested | Yes |
Audio File Support
| USB/Network Playback | Yes |
|---|---|
| Supported Formats | ALAC, AIFF, FLAC, WAV, AAC, MP3, DSD |
| Maximum PCM Resolution | 192 kHz/24-bit |
| Maximum DSD Resolution | 11.2 MHz |
Inputs & Outputs
| Analog Audio Inputs | 4 |
|---|---|
| Analog Audio Outputs | 2 |
| Subwoofer Pre-Outs | 2 |
| Speaker Outputs | 9 Channels |
| Zone 2 Pre/Line Out | Yes |
| 12V Trigger | 2 Outputs |
| IR Input/Output | 1 / 1 |
| RS-232C | Yes |
Features
| Room Calibration | Dirac Live and Advanced MCACC |
|---|---|
| Voice Control | Amazon Alexa and Google Assistant |
| Radio Tuner | DAB/FM |
| Radio Presets | 40 |
| App Control | Pioneer Remote App |
| Sonos Certified | Yes |
| Roon Tested | Yes |
Physical
| Color | Silver |
|---|---|
| Dimensions (W x H x D) | 435 x 173 x 370.5 mm |
| Weight | 10.4 kg |
| Power Consumption | 760 W |
| Standby Power Consumption | 0.1 W |
Packaging Info
| Package Weight | 13.5 kg |
|---|---|
| Box Dimensions (LxWxH) | 53.6 x 26.5 x 45.8 cm |
Identifiers
| MPN | VSXLX305 |
|---|---|
| GTIN / EAN / UPC | 4573211159233 |
