AMD Ryzen 5 8600G Processor Tray
General
| Product Name | AMD Ryzen™ 5 8600G |
|---|---|
| Family | AMD Ryzen |
| Series | AMD Ryzen 8000 Series |
| Product Type | Desktop Processor |
| Version | Tray Processor |
| Codename | Phoenix |
| Architecture | Zen 4 |
| Market Segment | Desktop |
| Launch Date | January 31, 2024 |
Processor
| CPU Cores | 6 |
|---|---|
| CPU Threads | 12 |
| Base Clock | 4.3 GHz |
| Max Boost Clock | Up to 5.0 GHz |
| Core Architecture | Zen 4 |
| Manufacturing Process | TSMC 4nm FinFET |
| L1 Cache | 384 KB |
| L2 Cache | 6 MB |
| L3 Cache | 16 MB |
| Total Cache | 22 MB |
| Simultaneous Multithreading | Yes |
| Instruction Set | x86-64 |
Platform
| CPU Socket | AM5 |
|---|---|
| Socket Type | LGA |
| Supported Chipsets | A620, B650, B650E, X670, X670E, X870, X870E, B850, B840 |
| PCI Express Version | PCIe 4.0 |
| Native PCIe Lanes | 20 |
| Usable PCIe Lanes | 10 |
Integrated Graphics
| Graphics Model | AMD Radeon™ 760M Graphics |
|---|---|
| Graphics Architecture | AMD RDNA™ 3 |
| Graphics Compute Units | 8 |
| Graphics Frequency | 2800 MHz |
| DirectX Support | DirectX 12 |
| OpenGL Support | OpenGL 4.6 |
| OpenCL Support | OpenCL 2.2 |
| Hardware Ray Tracing | Supported |
| AMD FreeSync | Supported |
Memory
| Memory Type | DDR5 |
|---|---|
| Memory Channels | 2 |
| Maximum Memory | 256 GB |
| Maximum Memory Speed | DDR5-5200 |
| Memory Configuration | 2 DIMMs per channel, dual-channel |
| ECC Support | Yes, requires motherboard support |
| AMD EXPO | Supported |
Display Support
| Maximum Displays | Up to 4 displays |
|---|---|
| DisplayPort | DisplayPort 2.1 |
| HDMI | HDMI 2.1 |
| Maximum Display Resolution | Up to 7680 x 4320 |
| DisplayPort Features | Adaptive-Sync, HDR Metadata, UHBR10 |
| HDCP | HDCP 2.3 |
Media Engine
| H.264 Encoding | Supported |
|---|---|
| H.265 Encoding | Supported |
| AV1 Encoding | Supported |
| H.264 Decoding | Supported |
| H.265 Decoding | Supported |
| AV1 Decoding | Supported |
| VP9 Decoding | Supported |
Connectivity
| USB 4 | Up to 2 ports, up to 40 Gbps |
|---|---|
| USB 3.2 Gen 2 | Up to 2 ports, up to 10 Gbps |
| USB 2.0 | Up to 1 port |
| NVMe RAID | RAID 0 and RAID 1 |
Power
| Default TDP | 65W |
|---|---|
| Configurable TDP | 45-65W |
| Maximum Temperature | 95°C |
| Thermal Solution | Not included with tray processor |
Overclocking
| CPU Overclocking | Unlocked |
|---|---|
| AMD Precision Boost Overdrive | Supported |
| AMD EXPO Technology | Supported |
| AMD Ryzen Master | Supported |
| Curve Optimizer | Supported |
Security
| AMD Secure Processor | Yes |
|---|---|
| AMD Memory Guard | Supported |
| AMD Enhanced Virus Protection | Supported |
| AMD-V Virtualization | Supported |
| NX Bit | Supported |
Processor Technologies
| AMD Precision Boost 2 | Supported |
|---|---|
| AMD Precision Boost Overdrive | Supported |
| AMD Smart Access Memory | Supported |
| AMD StoreMI | Supported |
| AMD FreeSync | Supported |
Operating System Support
| Windows | Windows 11 64-bit, Windows 10 64-bit |
|---|---|
| Linux | RHEL x86 64-bit, Ubuntu x86 64-bit |
Product Information
| Product Family | AMD Ryzen 5 |
|---|---|
| Series | Ryzen 8000G Series |
| Model | Ryzen 5 8600G |
| Processor Class | Ryzen 5 |
| Package | AM5 desktop processor, tray version |
| Integrated NPU | AMD Ryzen™ AI |
| NPU Architecture | AMD XDNA™ |
| NPU Performance | Up to 16 TOPS |
Identifiers
| MPN | 100-000001237 |
|---|---|
| GTIN / EAN / UPC | 8592978524906 |
