Huawei B535-235a wireless router Dual-band (2.4 GHz / 5 GHz) 4G White
Network
| Technology | UMTS / HSPA / HSPA+ / LTE |
|---|---|
| 3G Bands | UMTS B1 / B8 (2100 / 900 MHz) |
| 4G Bands | LTE FDD B1 / B3 / B7 / B8 / B20 / B28 / B32; LTE TDD B38 |
| LTE Category | LTE Cat 7 |
| Download Speed | Up to 300 Mbps |
| Upload Speed | Up to 100 Mbps |
| Carrier Aggregation | Supported; multiple LTE carrier aggregation combinations including B1, B3, B7, B8, B20, B28, B32 and B38 |
| LTE Transmission | FDD LTE / TDD LTE |
| 3G Data Speed | HSPA+ up to 42.2 Mbps |
| 5G Support | No |
Body
| Dimensions | 219 x 138 x 25.6 mm (8.62 x 5.43 x 1.01 in), excluding socket |
|---|---|
| Dimensions With Socket | 219 x 138 x 60.66 mm |
| Weight | Up to 330 g (0.33 kg), excluding power adapter |
| Build | Plastic housing |
| Color | White |
| SIM | 1 x Nano-SIM (4FF) |
| Installation | Desktop / tabletop |
| Status Indicators | LED status indicators |
Wi-Fi
| Standard | IEEE 802.11 a/b/g/n/ac (Wi-Fi 5) |
|---|---|
| Frequency | Dual-band 2.4 GHz / 5 GHz |
| 2.4 GHz Speed | Up to 400 Mbps theoretical |
| 5 GHz Speed | Up to 867 Mbps theoretical |
| 2.4 GHz MIMO | 2x2 MIMO |
| 5 GHz MIMO | 2x2 MIMO |
| Maximum Wi-Fi Users | Up to 64 simultaneous users |
| Wi-Fi Frequency Range | 2.4 GHz: 2401-2483 MHz; 5 GHz: 5170-5350 MHz and 5490-5710 MHz |
| Wi-Fi Features | Dual-band Wi-Fi, MIMO, WMM, wireless access point and hotspot functionality |
Ports
| WAN/LAN | 1 x Gigabit Ethernet RJ45, configurable as WAN or LAN |
|---|---|
| LAN | 3 x Gigabit Ethernet RJ45 |
| Total Ethernet Ports | 4 x Gigabit Ethernet ports |
| Telephone | 1 x RJ11 telephone port |
| LTE Antenna | 2 x external LTE antenna connectors, SMA |
| SIM Slot | 1 x Nano-SIM slot |
| USB | No USB data port |
| Reset | 1 x Reset button |
Antenna
| LTE Antenna | Built-in LTE main and diversity antennas |
|---|---|
| External Antenna | 2 x SMA external LTE antenna ports |
| LTE Antenna Configuration | 1T2R |
| LTE Antenna Gain | Approximately 1-2 dBi depending on LTE band |
| Wi-Fi Antenna | Built-in dual-band Wi-Fi antenna |
| 2.4 GHz Antenna Gain | Approximately 2.55 dBi |
| 5 GHz Antenna Gain | Approximately 2.9 dBi |
Connectivity
| Ethernet | Gigabit Ethernet 10/100/1000 Mbps |
|---|---|
| WAN | 1 x configurable Gigabit WAN/LAN port |
| LAN | 3 x Gigabit LAN ports |
| Mobile Network | 4G LTE / 3G UMTS |
| VoIP | Supported through telephone port and applicable operator configuration |
| SMS | SMS management supported through router interface/operator configuration |
Software
| Management | Web-based management interface and HUAWEI AI Life app |
|---|---|
| Routing Mode | NAT enabled by default; IP pass-through available depending on firmware/operator configuration |
| DHCP | DHCP server and IP address allocation |
| NAT | Supported |
| Firewall | Built-in firewall functions |
| VPN Client | L2TP and PPTP VPN client support |
| Multi APN | Supported optionally for data, voice and TR-069 services |
| TR-069 | Operator remote management supported optionally |
| TR-143 | Operator performance diagnostics supported optionally |
| Firmware Updates | Huawei Firmware Over The Air (HOTA) |
| WPS | Supported |
Security
| Wi-Fi Security | WEP, WPA, WPA-PSK, WPA2-PSK and applicable WPA/WPA2 encryption modes |
|---|---|
| Network Security | NAT and firewall protection |
| MAC Filtering | Supported depending on firmware |
| IP Filtering | Supported |
| URL Filtering | Supported depending on firmware |
Power
| Power Supply | External AC/DC power adapter |
|---|---|
| AC Input | 100-240 V AC, 50/60 Hz |
| DC Output | 12 V / 1 A |
| Power Consumption | Less than 12 W |
| Power Source | Mains power |
Operating Environment
| Operating Temperature | 0 °C to 40 °C |
|---|---|
| Storage Temperature | -20 °C to +70 °C |
| Operating Humidity | 5% to 95% relative humidity, non-condensing |
Memory
| Internal Memory | 256 MB |
|---|---|
| Flash Memory | 256 MB |
Features
| Wireless Networking | Dual-band 2.4 GHz and 5 GHz Wi-Fi 5 with 2x2 MIMO |
|---|---|
| Maximum Connections | Up to 64 simultaneous connected devices |
| WPS | Wi-Fi Protected Setup |
| SIM Management | Nano-SIM mobile broadband connectivity |
| External Antenna | Two SMA connectors for optional external LTE antennas |
| VoIP | Telephone service support through RJ11 where enabled by the operator |
| Access Management | Web interface and HUAWEI AI Life app |
| Firmware | Firmware Over The Air (HOTA) updates |
Performance
| Maximum LTE Download | 300 Mbps |
|---|---|
| Maximum LTE Upload | 100 Mbps |
| Maximum 2.4 GHz Wi-Fi | 400 Mbps theoretical |
| Maximum 5 GHz Wi-Fi | 867 Mbps theoretical |
| Maximum Combined Wi-Fi Rate | Up to 1167 Mbps theoretical |
| Maximum Users | 64 simultaneous users |
Certifications
| Compliance | WEEE, CE, Wi-Fi ERP, RoHS, REACH, GCF |
|---|
Package
| Router | Huawei B535-235a LTE CPE |
|---|---|
| Power Adapter | External AC/DC power adapter |
| Ethernet Cable | LAN RJ45 cable |
| Telephone Cable | Phone RJ11 cable |
| Documentation | Quick start guide/user documentation |
Identifiers
| MPN | B535-235a |
|---|---|
| GTIN / EAN / UPC | 6941487262335, 6901443359622 |
