Yamaha MG12XUK 12-Channel Mixing Console
| Built-in Effects | SPX algorithm: 24 programs, PARAMETER control:1, FOOT SW:1 (FX RTN CH on/off) |
|---|---|
| Phantom Power | +48 V switchable, channels 1 - 4 |
| Digital I/O | USB: USB Audio Class 2.0 compliant Sampling frequency: max 192 kHz Bit depth: 24-bit |
| Input Channels | 4x mono [mic/line] 2x mono/stereo [mic/line] 2x stereo [line] |
| Output Channels | 2x stereo out 1x monitor out 1x headphone out 2x aux out 2x group out |
| Bus | Stereo: 1 AUX: 2 GROUP: 2 |
| Pad | 26 dB (mono) |
| HPF | 80 Hz, 12 dB/oct (mono/stereo: MIC only) |
| Compressor | Threshold: +22 dBu to -8 dBu Ratio: 1:1 to 4:1 Output level: 0 dB to 7 dB Attack time: approx. 25 msec Release time: approx. 300 msec |
| Equalizer | EQ high gain: +15 dB/-15 dB, Frequency: 10 kHz shelving EQ mid gain: +15 dB/-15 dB, Frequency: 2.5 kHz peaking EQ low gain: +15 dB/-15 dB, Frequency: 100 Hz shelving |
| LED | Peak LED turns on when post EQ signal reaches 3 dB below clipping |
| Level Metering | 2 x 12-segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB] |
| Total Harmonic Distortion | 0.03% @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min, 0.005% @ +24 dBu (1 kHz), GAIN knob: Min |
| Frequency Response | +0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominal output level @ 1 kHz, GAIN knob: Min |
| Equivalent Input Noise | -128 dBu (mono input channel, Rs: 150 Ω, GAIN knob: max) |
| Residual Output Noise | -102 dBu (STEREO OUT, STEREO master fader: min) |
| Crosstalk | -78 dB |
| Power Requirement | AC 100 - 240 V, 50 / 60 Hz |
| Power Consumption | 22 W |
| Dimensions | 12.1 x 4.6 x 16.6" (308 x 118 x 422 mm) |
| Net Weight | 9.3 lb (4.2 kg) |
Packaging Info
| Package Weight | 13.05 lb |
|---|---|
| Box Dimensions (LxWxH) | 19.1 x 15.6 x 8" |
Identifiers
| MPN | MG12XUK |
|---|---|
| GTIN / EAN / UPC | 4957812624046 |
