GIGABYTE B650 GAMING X AX V2 Motherboard

Name: GIGABYTE B650 GAMING X AX V2 Motherboard
Brand: Gigabyte
SKU: 1119069
Price: 159.48 EUR
Availability: BackOrder

✔Smart Backup.
✔High-Speed USB.
✔Q-Flash Plus.
✔VRM Power Design.

Original price was: 196,41€.Current price is: 159,48€.

Price includes 21% VAT

Available for order (delivery in 2 - 4 business days)

Pay with Klarna

Pay immediately, after 30 days, or in installments.

2 years warranty

Free return for warranty service

14 days money back

Secure payment

Description

GIGABYTE B650 GAMING X AX V2 Motherboard

Platform

Product	GIGABYTE B650 GAMING X AX V2
Chipset	AMD B650
CPU Socket	AMD Socket AM5
Supported Processors	AMD Ryzen 7000 / Ryzen 8000 / Ryzen 9000 Series Processors
Motherboard Revision	Rev. 1.3
Form Factor	ATX
Dimensions	30.5 x 24.4 cm (12.0 x 9.6 in)

Memory

Memory Type	DDR5
Memory Slots	4 x DDR5 DIMM sockets
Maximum Memory	Up to 256 GB
Maximum Capacity Per DIMM	Up to 64 GB per DIMM
Memory Architecture	Dual-channel
Supported Memory Speed	DDR5-4400 / 4800 / 5200 / 5600 / 6000 / 6200 / 6400 / 6600 / 6800 / 7000 / 7200 / 7600 / 7800 / 8000 MT/s
Overclocked Memory	DDR5-8000 MT/s (OC)
Memory Type Support	Non-ECC Un-buffered DIMM, 1Rx8 / 2Rx8 / 1Rx16
AMD EXPO	Supported
Intel XMP	Supported

Expansion Slots

Primary PCI Express Slot	1 x PCI Express x16 slot integrated in CPU
Primary PCIe Interface	PCIe 4.0 x16 with AMD Ryzen 7000/9000 Series processors
Ryzen 8000 Phoenix 1	PCIe 4.0 x8
Ryzen 8000 Phoenix 2	PCIe 4.0 x4
Secondary PCIe Slots	2 x PCI Express x16 slots running at PCIe 3.0 x1
PCIe Graphics Support	Supports graphics cards and compatible NVMe SSD configurations
PCIe EZ-Latch	Supported on primary PCIe x16 slot

Storage

M.2 Slots	3 x M.2 Socket 3 connectors
M2A_CPU	PCIe 5.0 x4/x2, M key, supports 25110/22110/2580/2280 SSDs with Ryzen 7000/9000
M2B_CPU	PCIe 4.0 x4/x2, M key, supports 25110/22110/2580/2280 SSDs
M2C_SB	PCIe 4.0 x4/x2, M key, supports 25110/22110/2580/2280 SSDs
SATA Ports	4 x SATA 6Gb/s connectors
NVMe RAID	RAID 0, RAID 1 and RAID 10
SATA RAID	RAID 0, RAID 1 and RAID 10
M.2 Thermal Protection	M.2 Thermal Guard

Graphics

Integrated Graphics	AMD Radeon Graphics supported through compatible AM5 processors
DisplayPort	1 x DisplayPort 1.4
DisplayPort Maximum Resolution	3840 x 2160 @ 144 Hz
DisplayPort Features	HDR support
HDMI	1 x HDMI 2.1
HDMI Maximum Resolution	4096 x 2160 @ 60 Hz
HDMI Features	HDCP 2.3 and native HDMI 2.1 TMDS support

USB

Rear USB Type-C	1 x USB 3.2 Gen 2 Type-C, up to 10 Gb/s
Rear USB Type-A	1 x USB 3.2 Gen 2 Type-A, up to 10 Gb/s
Rear USB 3.2 Gen 1	3 x USB 3.2 Gen 1 ports
Rear USB 2.0	3 x USB 2.0/1.1 ports
Internal USB Type-C	1 x USB 3.2 Gen 2x2 Type-C header, up to 20 Gb/s
Internal USB 3.2 Gen 1	1 x USB 3.2 Gen 1 header
Internal USB 2.0	2 x USB 2.0/1.1 headers
Additional Internal USB 3.2 Gen 1	4 ports total, with 2 available through internal headers

Network

LAN Controller	Realtek 2.5GbE LAN
Ethernet Speed	2.5 Gbps / 1 Gbps / 100 Mbps
LAN Port	1 x RJ-45
LAN Features	2.5 Gigabit Ethernet connectivity

Wireless

Wi-Fi Module	Intel Wi-Fi 6E AX210
Wi-Fi Standard	IEEE 802.11 a/b/g/n/ac/ax
Wi-Fi Bands	2.4 GHz / 5 GHz / 6 GHz
Wi-Fi Generation	Wi-Fi 6E
Wireless Standard	802.11ax with 160 MHz channel support
Bluetooth	Bluetooth 5.3
Antenna	2 x SMA antenna connectors, 2T2R

Audio

Audio Codec	Realtek High Definition Audio CODEC
Audio Channels	2 / 4 / 5.1 / 7.1-channel
Audio Output	3 x audio jacks on rear I/O
Audio Features	High Definition Audio, Audio Noise Guard, high-end audio capacitors

Rear I/O

PS/2	1 x PS/2 keyboard/mouse port
Wi-Fi Antenna	2 x SMA antenna connectors
BIOS Update	1 x Q-Flash Plus button
DisplayPort	1 x DisplayPort
HDMI	1 x HDMI
USB Type-C	1 x USB 3.2 Gen 2 Type-C
USB 3.2 Gen 2 Type-A	1 x USB 3.2 Gen 2 Type-A
USB 3.2 Gen 1	3 x USB 3.2 Gen 1
USB 2.0	3 x USB 2.0/1.1
Ethernet	1 x RJ-45 2.5GbE
Audio	3 x audio jacks

Internal I/O

Main Power	1 x 24-pin ATX main power connector
CPU Power	1 x 8-pin ATX 12V + 1 x 4-pin ATX 12V
CPU Fan	1 x CPU fan header
CPU Pump	1 x CPU fan/water cooling pump header
System Fan	2 x system fan headers
System Fan/Pump	1 x system fan/water cooling pump header
M.2	3 x M.2 Socket 3 connectors
SATA	4 x SATA 6Gb/s connectors
Front Panel	1 x front panel header
Front Audio	1 x front panel audio header
Front USB Type-C	1 x USB 3.2 Gen 2x2 header
Front USB 3.2 Gen 1	1 x USB 3.2 Gen 1 header
USB 2.0 Headers	2 x USB 2.0/1.1 headers
TPM	1 x Trusted Platform Module header for GC-TPM2.0 SPI V2
Serial Header	1 x serial port header
Reset Button	1 x reset button
Reset Jumper	1 x reset jumper
Clear CMOS	1 x Clear CMOS jumper

Power & VRM

VRM Design	Direct 8+2+2 phase digital VRM solution
VRM MOSFET	60A DrMOS
CPU Power Connector	8+4-pin ATX 12V
PCB	6-layer PCB with 2X copper
PCB Design	PCIe 5.0-ready mid-loss PCB
Main Power Connector	24-pin ATX

Cooling

Fan Headers	5 x PWM/DC fan headers
CPU Fan Control	Supported
Water Pump Support	Supported
Temperature Monitoring	Voltage, temperature and fan speed detection
Water Flow Monitoring	Supported
Fan Fail Warning	Supported
Fan Stop	Supported
Smart Fan 6	Supported
Thermal Design	Fully covered MOSFET heatsinks and high thermal-conductivity thermal pads
M.2 Thermal Guard	Supported

BIOS

BIOS Type	AMI UEFI BIOS
BIOS Flash Memory	1 x 256 Mbit flash
Q-Flash	Supported
Q-Flash Plus	Supported
BIOS Update Without CPU	Supported through Q-Flash Plus
ACPI	ACPI 5.0
SMBIOS	SM BIOS 2.7
DMI	DMI 2.7
PnP	PnP 1.0a
WfM	WfM 2.0

Features

GIGABYTE Control Center	Supported
Q-Flash	Supported
Q-Flash Plus	Supported
Smart Backup	Supported
EZ-Latch	PCIe x16 quick-release design
RGB	RGB Fusion with addressable and RGB LED headers
Smart Fan 6	Advanced fan control with multiple temperature sensors and FAN STOP
Multi-Key	Multiple BIOS-configurable functions including reset, RGB switch, Direct-to-BIOS and Safe Mode

Operating System

Windows 11	Windows 11 64-bit supported
Windows 10	Windows 10 64-bit supported

Software

System Management	GIGABYTE Control Center
Security Software	Norton Internet Security OEM version
Backup	Smart Backup

Monitoring

Voltage Detection	Supported
Temperature Detection	Supported
Fan Speed Detection	Supported
Water Flow Detection	Supported
Fan Fail Warning	Supported
Fan Speed Control	Supported, depending on installed fan or pump

Operating Environment

Platform	Desktop PC motherboard
Installation	ATX-compatible PC chassis
CPU Platform	AMD AM5
Memory Platform	DDR5

Identifiers

MPN	B650 GAMING X AX V2 1.2
GTIN / EAN / UPC	4719331860073
