GIGABYTE B650 GAMING X AX V2 Motherboard
Platform
| Product | GIGABYTE B650 GAMING X AX V2 |
|---|---|
| Chipset | AMD B650 |
| CPU Socket | AMD Socket AM5 |
| Supported Processors | AMD Ryzen 7000 / Ryzen 8000 / Ryzen 9000 Series Processors |
| Motherboard Revision | Rev. 1.3 |
| Form Factor | ATX |
| Dimensions | 30.5 x 24.4 cm (12.0 x 9.6 in) |
Memory
| Memory Type | DDR5 |
|---|---|
| Memory Slots | 4 x DDR5 DIMM sockets |
| Maximum Memory | Up to 256 GB |
| Maximum Capacity Per DIMM | Up to 64 GB per DIMM |
| Memory Architecture | Dual-channel |
| Supported Memory Speed | DDR5-4400 / 4800 / 5200 / 5600 / 6000 / 6200 / 6400 / 6600 / 6800 / 7000 / 7200 / 7600 / 7800 / 8000 MT/s |
| Overclocked Memory | DDR5-8000 MT/s (OC) |
| Memory Type Support | Non-ECC Un-buffered DIMM, 1Rx8 / 2Rx8 / 1Rx16 |
| AMD EXPO | Supported |
| Intel XMP | Supported |
Expansion Slots
| Primary PCI Express Slot | 1 x PCI Express x16 slot integrated in CPU |
|---|---|
| Primary PCIe Interface | PCIe 4.0 x16 with AMD Ryzen 7000/9000 Series processors |
| Ryzen 8000 Phoenix 1 | PCIe 4.0 x8 |
| Ryzen 8000 Phoenix 2 | PCIe 4.0 x4 |
| Secondary PCIe Slots | 2 x PCI Express x16 slots running at PCIe 3.0 x1 |
| PCIe Graphics Support | Supports graphics cards and compatible NVMe SSD configurations |
| PCIe EZ-Latch | Supported on primary PCIe x16 slot |
Storage
| M.2 Slots | 3 x M.2 Socket 3 connectors |
|---|---|
| M2A_CPU | PCIe 5.0 x4/x2, M key, supports 25110/22110/2580/2280 SSDs with Ryzen 7000/9000 |
| M2B_CPU | PCIe 4.0 x4/x2, M key, supports 25110/22110/2580/2280 SSDs |
| M2C_SB | PCIe 4.0 x4/x2, M key, supports 25110/22110/2580/2280 SSDs |
| SATA Ports | 4 x SATA 6Gb/s connectors |
| NVMe RAID | RAID 0, RAID 1 and RAID 10 |
| SATA RAID | RAID 0, RAID 1 and RAID 10 |
| M.2 Thermal Protection | M.2 Thermal Guard |
Graphics
| Integrated Graphics | AMD Radeon Graphics supported through compatible AM5 processors |
|---|---|
| DisplayPort | 1 x DisplayPort 1.4 |
| DisplayPort Maximum Resolution | 3840 x 2160 @ 144 Hz |
| DisplayPort Features | HDR support |
| HDMI | 1 x HDMI 2.1 |
| HDMI Maximum Resolution | 4096 x 2160 @ 60 Hz |
| HDMI Features | HDCP 2.3 and native HDMI 2.1 TMDS support |
USB
| Rear USB Type-C | 1 x USB 3.2 Gen 2 Type-C, up to 10 Gb/s |
|---|---|
| Rear USB Type-A | 1 x USB 3.2 Gen 2 Type-A, up to 10 Gb/s |
| Rear USB 3.2 Gen 1 | 3 x USB 3.2 Gen 1 ports |
| Rear USB 2.0 | 3 x USB 2.0/1.1 ports |
| Internal USB Type-C | 1 x USB 3.2 Gen 2x2 Type-C header, up to 20 Gb/s |
| Internal USB 3.2 Gen 1 | 1 x USB 3.2 Gen 1 header |
| Internal USB 2.0 | 2 x USB 2.0/1.1 headers |
| Additional Internal USB 3.2 Gen 1 | 4 ports total, with 2 available through internal headers |
Network
| LAN Controller | Realtek 2.5GbE LAN |
|---|---|
| Ethernet Speed | 2.5 Gbps / 1 Gbps / 100 Mbps |
| LAN Port | 1 x RJ-45 |
| LAN Features | 2.5 Gigabit Ethernet connectivity |
Wireless
| Wi-Fi Module | Intel Wi-Fi 6E AX210 |
|---|---|
| Wi-Fi Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Wi-Fi Bands | 2.4 GHz / 5 GHz / 6 GHz |
| Wi-Fi Generation | Wi-Fi 6E |
| Wireless Standard | 802.11ax with 160 MHz channel support |
| Bluetooth | Bluetooth 5.3 |
| Antenna | 2 x SMA antenna connectors, 2T2R |
Audio
| Audio Codec | Realtek High Definition Audio CODEC |
|---|---|
| Audio Channels | 2 / 4 / 5.1 / 7.1-channel |
| Audio Output | 3 x audio jacks on rear I/O |
| Audio Features | High Definition Audio, Audio Noise Guard, high-end audio capacitors |
Rear I/O
| PS/2 | 1 x PS/2 keyboard/mouse port |
|---|---|
| Wi-Fi Antenna | 2 x SMA antenna connectors |
| BIOS Update | 1 x Q-Flash Plus button |
| DisplayPort | 1 x DisplayPort |
| HDMI | 1 x HDMI |
| USB Type-C | 1 x USB 3.2 Gen 2 Type-C |
| USB 3.2 Gen 2 Type-A | 1 x USB 3.2 Gen 2 Type-A |
| USB 3.2 Gen 1 | 3 x USB 3.2 Gen 1 |
| USB 2.0 | 3 x USB 2.0/1.1 |
| Ethernet | 1 x RJ-45 2.5GbE |
| Audio | 3 x audio jacks |
Internal I/O
| Main Power | 1 x 24-pin ATX main power connector |
|---|---|
| CPU Power | 1 x 8-pin ATX 12V + 1 x 4-pin ATX 12V |
| CPU Fan | 1 x CPU fan header |
| CPU Pump | 1 x CPU fan/water cooling pump header |
| System Fan | 2 x system fan headers |
| System Fan/Pump | 1 x system fan/water cooling pump header |
| M.2 | 3 x M.2 Socket 3 connectors |
| SATA | 4 x SATA 6Gb/s connectors |
| Front Panel | 1 x front panel header |
| Front Audio | 1 x front panel audio header |
| Front USB Type-C | 1 x USB 3.2 Gen 2x2 header |
| Front USB 3.2 Gen 1 | 1 x USB 3.2 Gen 1 header |
| USB 2.0 Headers | 2 x USB 2.0/1.1 headers |
| TPM | 1 x Trusted Platform Module header for GC-TPM2.0 SPI V2 |
| Serial Header | 1 x serial port header |
| Reset Button | 1 x reset button |
| Reset Jumper | 1 x reset jumper |
| Clear CMOS | 1 x Clear CMOS jumper |
Power & VRM
| VRM Design | Direct 8+2+2 phase digital VRM solution |
|---|---|
| VRM MOSFET | 60A DrMOS |
| CPU Power Connector | 8+4-pin ATX 12V |
| PCB | 6-layer PCB with 2X copper |
| PCB Design | PCIe 5.0-ready mid-loss PCB |
| Main Power Connector | 24-pin ATX |
Cooling
| Fan Headers | 5 x PWM/DC fan headers |
|---|---|
| CPU Fan Control | Supported |
| Water Pump Support | Supported |
| Temperature Monitoring | Voltage, temperature and fan speed detection |
| Water Flow Monitoring | Supported |
| Fan Fail Warning | Supported |
| Fan Stop | Supported |
| Smart Fan 6 | Supported |
| Thermal Design | Fully covered MOSFET heatsinks and high thermal-conductivity thermal pads |
| M.2 Thermal Guard | Supported |
BIOS
| BIOS Type | AMI UEFI BIOS |
|---|---|
| BIOS Flash Memory | 1 x 256 Mbit flash |
| Q-Flash | Supported |
| Q-Flash Plus | Supported |
| BIOS Update Without CPU | Supported through Q-Flash Plus |
| ACPI | ACPI 5.0 |
| SMBIOS | SM BIOS 2.7 |
| DMI | DMI 2.7 |
| PnP | PnP 1.0a |
| WfM | WfM 2.0 |
Features
| GIGABYTE Control Center | Supported |
|---|---|
| Q-Flash | Supported |
| Q-Flash Plus | Supported |
| Smart Backup | Supported |
| EZ-Latch | PCIe x16 quick-release design |
| RGB | RGB Fusion with addressable and RGB LED headers |
| Smart Fan 6 | Advanced fan control with multiple temperature sensors and FAN STOP |
| Multi-Key | Multiple BIOS-configurable functions including reset, RGB switch, Direct-to-BIOS and Safe Mode |
Operating System
| Windows 11 | Windows 11 64-bit supported |
|---|---|
| Windows 10 | Windows 10 64-bit supported |
Software
| System Management | GIGABYTE Control Center |
|---|---|
| Security Software | Norton Internet Security OEM version |
| Backup | Smart Backup |
Monitoring
| Voltage Detection | Supported |
|---|---|
| Temperature Detection | Supported |
| Fan Speed Detection | Supported |
| Water Flow Detection | Supported |
| Fan Fail Warning | Supported |
| Fan Speed Control | Supported, depending on installed fan or pump |
Operating Environment
| Platform | Desktop PC motherboard |
|---|---|
| Installation | ATX-compatible PC chassis |
| CPU Platform | AMD AM5 |
| Memory Platform | DDR5 |
Identifiers
| MPN | B650 GAMING X AX V2 1.2 |
|---|---|
| GTIN / EAN / UPC | 4719331860073 |
